M23 Power Series 4-Pin Male Socket Connector | Square Flange Panel Mount | Industrial Circular Power Connector
Product Overview
The M23 Power 4-Pin (3+PE) Male Panel Mount Connector is engineered for high-performance power transmission in demanding industrial environments. Designed specifically for power supply and motor applications, it features a robust metal housing and high-conductivity gold-plated contacts to ensure maximum reliability and safety under heavy electrical loads.
1. High Power Transmission Capacity
Designed for 4-pin configurations (typically 3 Power + 1 PE/Ground), this connector handles high currents and voltages, making it the industry standard for servo motors, drives, and power distribution units.
2. Industrial-Grade Durability
-
Housing: High-strength Zinc Alloy with Nickel plating for superior corrosion resistance and electromagnetic interference (EMI) shielding.
-
Inserts: Heat-resistant PA66/PBT plastic, ensuring stability in high-temperature environments.
-
Contacts: Precision-machined copper alloy with gold plating for low contact resistance and over 500 mating cycles.
3. IP67 Waterproof & Dustproof
When mated, the connector achieves an IP67/IP68 rating, providing a complete seal against moisture, oil, and dust. Perfect for harsh factory floors and outdoor equipment.
4. Secure Flange Mounting
The 4-hole square flange design allows for secure, vibration-resistant installation on panels or enclosures. Includes a high-quality O-ring seal to prevent leaks at the mounting point.
Technical Specifications
| Specification | Details |
| Series | M23 Power Series |
| Pin Count | 4 Pin |
| Gender | Male Socket (Male Pins) |
| Mounting Type | Square Flange Panel Mount |
| Locking Mechanism | Threaded M23 x 1.0 |
| Termination Method | Crimp |
| Rated Current | Up to 28A / 30A (Depending on wire gauge) |
| Rated Voltage | 630V AC/DC |
| Protection Level | IP67 / IP68 (Mated) |
| Operating Temp | -40℃ to +125℃ |
Typical Applications
-
Servo Motors & Drives: Feedback and power supply for CNC machines and robotics.
-
Factory Automation: Power distribution for conveyor systems and sensors.
-
Renewable Energy: Inverters and battery storage systems.
-
Heavy Machinery: Construction and agricultural electronic control units.
Why Choose Our M23 Connectors?
-
Vibration Resistant: The threaded locking system prevents accidental disconnection in high-vibration environments.
-
Easy Assembly: Modular design allows for quick field assembly or factory pre-wiring.
-
Standard Compatibility: Fully compatible with major international brands (Intercontec, Phoenix, TE style).
